| Model | UMC6000-N1 |
| DVI Input Card |
| Port Type | DVI-I |
| Per Card Port Quantity | 4 Channels |
| Maximum Resolution | 1920×1200@60Hz |
| Adaptable Signal Type | VGA/DVI/HDMI(Adapter) |
| Digital Protection | Support HDCP |
| IP Decoding Input Card |
| Port Type | RJ-45 1G |
| Max Resolution | 4K |
| Decoding Capacity | 1 CH 4K,4 CH Pixel-to-Pixel 1080Pl,16 CH Compressed 1080P ,32 CH 720P. |
| Supported Protocol | ONVIF，RTSP |
| Decoding Format | H.264，H.265 |
| 4K HDMI Input Card |
| Port Type | HDMI |
| Per Card Port Quantity | 4 channels |
| Maximum Resolution | 3840×2160@30Hz, 2560 x 1600@60Hz |
| FHD HDMI Input Card |
| Port Type | HDMI |
| Per Card Port Quantity | 8 channels |
| Max. Resolution | 1920 x 1200 @60HZ |
| Digital Projection | HDCP |
| Video Input Card |
| Port Type | BNC |
| Video Format | PAL/NTSC |
| Per Card Port Quantity | 4 Channels |
| Max. Resolution | PAL:720 x 576@25fps/s, NTSC: 720 x 478@ 30fps/s |
| Fiber Input Card |
| Port Type | LC ( configure input node) |
| Per Card Port Quantity | 4 Channels |
| Data Capacity | 40Gbps |
| Max. Distance | 10KM |
| DVI Output Card |
| Port Type | DVI-D |
| Max. Resolution | 1920*1200@60Hz(customize) |
| Per Card Port Quantity | 4 channel |
| HDMI Output Card |
| Port Type | HDMI |
| Per Card Port Quantity | 8 Channels |
| Max. Resolution | 1920 x 1200 @60 HZ |
| DP Output Card |
| Port Type | DP |
| Per Card Port Quantity | 2 Channels |
| Max. Resolution | 3840 x 2160 @ 30 HZ |
| General |
| Control System | Windows/Android |
| Network Protocol | TCP/IP |
| 2U Chassis | TBD |
| 4U Chassis | 482(W)×178(H)×300(D)(mm)/ 11kg (Full Card)/10 Slots |
| 7U Chassis | 482(W)×311(H)×300(D)(mm)/ 20kg (Full Card)/20 Slots |
| 13U Chassis | 482(W)×577(H)×300(D)(mm/ 38kg (Full Card)/40Slots |
| Power Voltage | 100-240V, AC 5A,50/60HZ |
| Power Consumption | ≤480W,Redundant |
| Redundant Power | Optional |
| Operating Humidity | 10 %～90%, no-condensing |
| Running Temperature | 0°C～40°C |
| Storage Temperature | -20°C-70°C |
| Attitude | Up to 5000m |
