ITC200 |
| Thermal Camera |
| Maximum image size |
640×512@30fps |
384×288@30fps |
| Pixel Size |
14llm |
17llm |
| Response Waveband |
8~14llm |
| NETD |
≤50 mK (@25℃, F#1.0) |
| Focal length |
25mm/19mm/13mm |
13mm/9.7mm/4mm |
| FOV |
25mm: 17.5°×14.0°
19mm: 22.9°×18.4°
13mm: 32.9°×26.6° |
13mm: 28.2°×21.3°
9.7mm: 37.2°×28.3°
4mm: 78.4°×62.9° |
| Palette |
18 color palettes and fusion with visible |
| Visual Camera |
| Sensor |
1/2.9 inches CMOS |
| Resolution |
2MP |
| IR
Illumination |
Support |
| Network |
| Network Protocol |
ICMP, TCP, UDP, RTP, RTSP, DHCP, PPPOE, UPNP, DDNS, ONVIF, FTP
and GB/T 28181 etc. |
| Video Compression |
H.264/H.265 |
| Functions |
| Measurement
Modes |
Support point, line, area, full screen and shield measurement
modes,
above modes can be set independently. |
| Temperature Range |
-20℃ ~ +60℃ |
| Temperature Accuracy |
±2℃ or
±2%, whichever is greater
(Take the maximum value)* |
| Temperature Alerts |
4 temperature rules (above high, below low, in between, out of
range), and support area temperature comparison. |
| Smart Functions |
Fire point & intensity, line crossing, area entrance &
exiting alarm |
| Audio
Interface |
1 channel input/1 channel output |
| System Integration |
| Communication Interface |
RJ45 10M/100M self-adaptive; RS485 |
| Alarm Interface |
1 channel input/1
channel output |
| General |
| Working Ambient |
Working humidity ≤95% non-condensation |
| IP Rating |
IP66 |
| Power Supply/ Consumption |
DC12V; ≤10W |
| Dimension/Weight |
334.5×121.5×112.5(mm);
≤1.6kg |
